Resin Bonded Filter Cartridges - MRB
High-Performance Resin Bonded Filters for Superior Industrial Filtration.
High-Performance Resin Bonded Filters for Superior Industrial Filtration.
The mmp® MRB Series Cartridges feature a specialized filtration design that maximizes particle retention and extends service life, all while maintaining a durable, resin-bonded porosity structure. Perfect for filtering viscous fluids in industrial applications.
To ensure compatibility across a broad range of process fluids and performance demands, MRB series cartridges incorporate a carefully selected blend of advanced fibers. This blend creates a gradual tightening structure with uniform micropore size and high porosity, allowing larger particles to be captured on the surface while smaller particles are trapped deeper within. This design enhances retention capacity and extends the cartridge's lifespan, all while providing exceptional cartridge strength.
Available in both grooved and ungrooved versions, the mmp® MRB series resin-bonded filters are ideal for various applications, offering versatile and reliable performance for even the most demanding environments.
| Operating Data* | RBF Series |
| Material | 135°C |
| Operating Pressure | 0.45MPa |
| Solvent Resistance | Expansion rate <2% (Ketones, Ethers, Phenols, Alcohols etc.) |
| Anti-shrinkage | No shrinkage and depression |
| Inner Diameter | 29mm |
| Outer Diameter | 63-65mm |
| Length | 3.75 to 40 inch |
| Micro Rating | 1, 5, 10, 25, 50, 75, 100, 125, 150, 200μm |
| Model | Micron | Length | Adapter |
| MRB | 5=5µm | 248 = 9.75inch | DOE = Double Open End |
P/N.: MRB-5-248-DOE
*The information supplied above is based on analysis of production trend. This is subject to change without notice if future trends are adjusted. They are listed for information purposes only and not to be used as purchase specifications. Different lengths and micron ratings are available upon request.
1
Two-stage design ensures stability, resisting collapse under high pressure.
2
Enhanced retention extends service life and efficiency.
3
Available in multiple sizes to meet diverse filtration needs.
4
Compatible with a wide range of industrial chemicals for versatile use.
mmp’s MRB Series Resin Bonded Filter Cartridges offer high dirt-holding capacity, graded porosity, and excellent chemical resistance. Designed for industrial use, they efficiently filter paints, adhesives, solvents, and viscous fluids under high-pressure conditions. mmp is a leading name in advanced filtration, delivering reliable and high-performance solutions across industries.
Cross-sectional view for graded porosity of MRB series resin bonded filter
Chemical
Petrochemicals
Paints
Coatings
Food
Beverages
Automotive
